LIFEPAK CR2 AED

Advanced Connected AED Technology for Equestrian Facilities

The LIFEPAK CR2 AED is designed to help rescuers respond quickly and confidently during sudden cardiac arrest emergencies. Combining advanced CPR guidance, connected monitoring technology, fast shock delivery, and rugged durability, the LIFEPAK CR2 is an ideal safety solution for equestrian facilities, barns, arenas, riding schools, competition venues, and outdoor events.

Built for both trained responders and first-time rescuers, the LIFEPAK CR2 provides intuitive guidance and innovative technology to help improve emergency response when every second matters.

Faster Time to First Shock

The LIFEPAK CR2 features an intuitive layered design with bold graphics and easy-to-follow instructions that help rescuers begin treatment quickly and efficiently.

Compared to some traditional AEDs, the device is designed to help deliver a first shock significantly faster, helping maximize the chances of survival during sudden cardiac arrest emergencies.

Quick-Access QUIK-STEP™ Electrodes

Electrodes peel directly from the base for faster placement
Simplified design supports rapid deployment during emergencies

cprINSIGHT™ Analysis Technology

The LIFEPAK CR2 features innovative cprINSIGHT™ technology, allowing the AED to analyze heart rhythm while CPR is actively being performed.

This advanced feature helps:

Reduce pauses in chest compressions
Increase CPR efficiency
Minimize interruptions during rescue efforts

By allowing rhythm analysis during CPR, the device helps rescuers maintain continuous lifesaving compressions.

cprCOACH™ CPR Guidance

The built-in cprCOACH™ system provides step-by-step audio guidance throughout the rescue process, including:

Hand placement instructions
Compression pacing guidance
Compression depth reminders
CPR cycle timing prompts

An integrated metronome helps rescuers maintain an effective compression rate for high-quality CPR delivery.

Connected AED Monitoring & Data Transfer

Optional connected 4G cellular capabilities help facilities monitor AED readiness and improve emergency communication across multiple buildings and locations.

Connected AED Features

Automatic daily self-tests and software updates
Wireless AED status monitoring
AED location tracking
Event data transfer to emergency responders
Connectivity support for outdoor and remote locations

The system helps ensure AEDs remain rescue-ready while simplifying program management for equestrian facilities and event operations.

ClearVoice™ Technology

Equestrian environments can often be noisy and fast-paced. The LIFEPAK CR2 uses ClearVoice™ technology to automatically adjust audio volume and voice prompts based on surrounding noise levels, helping ensure instructions remain easy to hear during an emergency.

Flexible Rescue Options

The LIFEPAK CR2 is available in:

Fully automatic models
Semi-automatic models

Child Mode

Integrated Child Mode allows rescuers to switch to pediatric rescue settings without changing electrodes, making the device ready to assist both adults and children quickly and easily.

Bilingual Capability

The AED can be configured with two preset languages, allowing users to toggle between languages during operation when needed.

Rugged LIFEPAK TOUGH™ Design

Built for demanding environments, the LIFEPAK CR2 is designed to withstand dust, moisture, vibration, shock, and temperature extremes commonly encountered in barns, arenas, and outdoor equestrian events.

Durability Features

IP55-rated dust and water resistance
Shock and vibration tested
Suitable for indoor and outdoor use
Backed by an 8-year warranty

Key Features

cprINSIGHT™ rhythm analysis during CPR
cprCOACH™ CPR guidance system
Rapid shock delivery with reduced CPR interruptions
QUIK-STEP™ fast-access electrodes
ClearVoice™ adaptive audio technology
Escalating energy shocks up to 360J
Integrated Child Mode without changing pads
Bilingual operation capability
Optional 4G cellular AED connectivity
LIFELINKcentral™ AED program management compatibility
Rugged LIFEPAK TOUGH™ IP55-rated construction
Available in fully automatic or semi-automatic configurations

Technical Specifications

Defibrillation Technology

Biphasic Truncated Exponential waveform with patient impedance compensation
Patient impedance range: 10–300 ohms

Energy Levels

Adult

200J, 300J, 360J escalating energy sequence

Pediatric

50J, 75J, 90J

Shock Timing

Semi-automatic: Shock delivery in under 7 seconds after CPR
Fully automatic: Shock delivery in under 13 seconds after CPR

Shock Advisory System™

Automatically analyzes ECG rhythms and determines if a shock is required

CPR Guidance Features

CPR rate and depth guidance
Compression metronome
Hand placement instructions
Audio prompts and rescue coaching
CPR feedback when compressions are not detected

User Interface & Controls

Controls

Lid release with integrated On/Off control
Shock button (semi-automatic models)
Automatic shock delivery (fully automatic models)
Child Mode selection button
Optional language selection button

Audio Guidance

Voice prompts and audible rescue tones
ClearVoice™ adaptive volume adjustment for noisy environments

Status Indicators

Visual and audible readiness indicators for device, pads, and battery

Environmental Specifications

Operating Conditions

Operating Temperature: 32°F to 122°F (0°C to 50°C)
Storage Temperature: -22°F to 140°F (-30°C to 60°C)
Humidity Range: 5%–95% non-condensing
Altitude Range: -1,253 to 15,000 feet

Durability

IP55 dust and water resistance
Shock tested to IEC standards
Vibration tested to MIL-STD helicopter and ground vehicle standards

Physical Specifications

Height: 3.8" (9.7 cm)
Width: 8.9" (22.6 cm)
Depth: 10.8" (27.4 cm)
Weight: 4.5 lbs (2.0 kg) with battery and electrodes installed

Battery & Electrode Information

Battery

Lithium manganese dioxide battery
Up to 166 shocks at 200J
Up to 103 shocks at 360J
Approximately 800 minutes of operating time
Up to 4-year standby life

Electrode Pads

Adult and pediatric compatible electrodes
Rapid-access packaging design
Replace every 4 years or after use

Data Storage & Connectivity

Event Storage

Internal digital memory (flash RAM)
Stores a minimum of 60 minutes of ECG data for two patient events

Communications

USB connectivity
Wireless 802.11 b/g/n data transfer
Compatible with LIFELINKcentral™ AED program manager and LIFENET® System

The LIFEPAK CR2 AED combines advanced CPR technology, connected readiness monitoring, rugged durability, and intuitive rescue guidance to help equestrian facilities strengthen emergency preparedness and respond confidently during sudden cardiac arrest emergencies.

What's Included:

Physio Control LIFEPAK CR2
Handle or Bag
QUICK-STEP adult/child pacing/ECG/defibrillation electrodes (with 4-year warranty)
Battery Pack
Premium AED/CPR Responder® Pack
"AED Equipped" Window/Wall Decal
AED Check® Tag
Physician's Prescription

Recommended Items (Sold Separately)

AED Cabinet
AED Management Program (Not required but highly recommended)
Pediatric electrode pads
Spare set of Adult Electrode Pads
CPR/AED First Aid Course (May be required by State)
Emergency Action Plan (May be required by State)

LIFEPAK CR2 Brochure

LIFEPAK CR2 Data Sheet
