For your Cardiac Science Powerheart G5 AED we offer a variety of

Cardiac Science Cabinets and AIVIA OUTDOOR Cabinets that can be climate controlled.

Cardiac Science AED Cabinets

Compatible with all Cardiac Science AEDs
Material: Stainless steel
Included: All hardware and two keys
Spare Key: Part Number 50-00599-01

Mount Options:

Surface Mount
Semi-Recessed
Fully-recessed

Security Options:

No Security (No alarm or strobe)
Alarm Only
Alarm & Strobe

Security Enabled

Alarm Only: When the cabinet door is opened; an audible alarm is activated.

Alarm & Strobe: When the cabinet door is opened, an audible alarm and a visual flashing strobe light are activated.

The cabinet is security-enabled by wiring into a building’s security system. A key that allows you to enable or disable the alarm is included.

The Strobe Light is mounted above the cabinet in the Recessed and Semi-Recessed Options.

Please consider horse and other animal potential reactions when choosing a security option.

Cabinet Sizes

Surface Mount Sizing

Internal (H/W/D): 14.25 in (36.20 cm) X 14.25 in (36.20 cm) X 7 in (17.78 cm)

External (H/W/D): 17.5 in (44.45 cm) X 17.5 in (44.45 cm) X 7 in (17.78 cm)

Protrusion from the wall: 7 in (17.78 cm)

Semi-Recessed Mount Sizing

Internal (H/W/D): 14.25 in (36.20 cm) X 14.25 in (36.20 cm) X 7 in (17.78 cm)

External (H/W/D): 17.5 in (44.45 cm) X 17.5 in (44.45 cm) X 7 in (17.78 cm)

Protrusion from the wall: 3.12 in (7.92 cm)

Fully-Recessed Mount Sizing

Internal Dimensions: 14.125"H x 14.125"W x 7"D

Please Note: When selecting a location for your AED cabinet, please prioritize the safety of both personnel and horses. A surface-mounted cabinet requires less preparation and can be installed directly on a wall, but placement should avoid areas where it could be bumped or struck. Choose a location that is both visible for easy access and out of high-traffic zones. If the cabinet will be in areas frequented by horses, consider a fully recessed or semi-recessed cabinet to reduce the risk of accidental contact while maintaining accessibility.

OUTDOOR CABINETS

AIVIA 200 AED Wall Cabinet

The AIVIA 200 is a versatile indoor/outdoor cabinet designed to securely store your AED in any environment.

Important: The power supply must be hardwired by a licensed electrician to operate the cabinet’s heater, fan, and alarm system.

This cabinet features an optional heating and cooling fan activated by a temperature sensor with adjustable thresholds, natural ventilation, and an alarm system with a flashing white LED that is both visible and audible when the door is unlocked. The AIVIA 200 is compatible with all AED models, providing reliable protection and easy access whenever it’s needed.
